MV

We are partnered with Siemens to provide Medium Voltage (MV) solutions upto 36kV, 3150A.

We offer solutions with both IVAC (Breaker only) and IPAN (Breaker and Enclosure) models. Both designs are fully type tested per IEC 62271. Ingress protection upto IP54 is available ensuring best in class safety and performance. We have custom engineering solutions for 6.6kV, 11kV and 33kV requirements.

Both our designs are custom made to meet all customer requirements and to also ensure a reliable power supply while maintaining stringent safety standards.

In addition we also offer Medium Voltage Motor Control solutions with Vacuum Contactor and Isolation Switch in the same Panel.

Our entire range is available with both Aluminum and Copper busbar solutions, allowing more flexibility to our users.

Features:

• Compliance to latest IEC standard IEC 62271 -1 and 200
• Designed up to 36kV, 3150 A
• Short Circuit Withstand capacity up to 40 kA for 3s
• Ingress Protection up to IP54
• Fully Mechanical Interlocking System
• Extendable with PM Class Partitions

• Drawout type Circuit Breakers (both 12kV and 36kV)

• Isolation from live parts with metal shutters

• In House Routine Testing Facility
